TECHNICAL SPECIFICATION

- 22 -

Item Specification Item Specification

Size (L × W × H) 2180mm×730mm×1300mm Lubricate method Pressure & splash

Wheelbase 1500mm Starting method Electrical start / kick start

Net weight 125kg Spark plug type A7TC or A7RTC

Max. load 175kg Clutch type Dry and automatic

Max. speed ≥80Km/h(125) ≥95Km/h(150) Front wheel 100/80-16

Tire model/air pressure

Max. slope ≥21° Rear wheel 110/80-16

Min clearance 170mm

Brake type Front: Disc; Rear: Disc

Max. driven noise ≤77 dB(A)

Front: Spring liquid flex

Shock absorb method

Fuel tank capacity 9 L

Rear: Spring oil damp

Oil tank capacity 0.9L

Headlight 12V 35W/35W

Engine oil type SAE 15W-40

Position light 12V 3W

Engine model 152QMI (125) 157QMJ (150)

Turning signal light 12V 5W / 21W

Engine type Single cylinder, air cool, 4-stroke

Taillight / brake light 12V 5W / 21W

Bore × stroke 52.4mm×57.8mm(125) 57.4mm×57.8mm(150)

Meter light 12V 3W

Cylinder work capacity 124.9ml (125) 119.5ml (150)

Far beam indicator 12V 3W

Compression ratio 9.0 : 1

Turning signal indicator 12V 3W

Max. power / rotate speed 5.8kw / 7500(r/min)(125) 7.0 kw / 7500(r/min)(150)

Mobile indicator 12V 3W

Max. torque / rotate speed 7.8N.m / 5500(r/min)(125) 9.0N.m / 5500(r/min)(150)

Fuse 15A

Ignition method C.D.I

Battery 12V7AH
