PARTS LIST
MAIN
PRINTED CIRCUIT BOARD ASSEMBLY (CONT)
QTY PART # DESCRIPTION REFERENCE DESIGNATION
1 041465 XSTR N-CH JFET J113 TO-92 Q1
5 016739 XSTR NPN 2N4401 TO-92 Q8 Q7 Q6 Q4 Q5
EFFECTS PCB ASSEMBLY
1 053963 PCB FAB FX MODEL T
1 048914 CABLE RIBBON 8 CKT 7 in @P15
1 038690 CAP AE AX 1.0uF 100V C30
1 009512 CAP AE AX 22uF 25V 20% C28
1 027286 CAP MPF .47uF 63V C39
1 024823 CAP MPF RDL .01uF 400V 10% C25
1 024845 CAP MPF RDL .047uF 400V 10% C29
1 024853 CAP MPF RDL .1uF 250V 10% C27
1 024876 CAP MPF RDL .68uF 250V 10% C26
4 047540 CONTROL SNAPIN 250k 15A R49 R51 R63 R65
5 006260 DIODE 1N4448 SIGNAL LL CR5-6 CR10 CR20 CR26
1 031635 DIODE ZEN 1N5240B 10V 5% LL CR4
2 031019 DIODE ZEN 1N5245B 15V 5% LL CR7-8
4 037036 JACK PHONE PCB MONO CA PREMIUM J2 J4 J5-6
1 031570 JACK PHONE PCB STEREO PREMIUM J3
2 036613 RELAY DPDT DIP 24 VOLT 8.3mA K3-4
2 025116 RES CF 1/2W 5% 100k LL R57 R69
2 024969 RES CF 1/4W 5% 1.5k LL R56 R70
4 024937 RES CF 1/4W 5% 10 ohm LL R61 R74 R79 R80
1 024997 RES CF 1/4W 5% 100k LL R62
2 024981 RES CF 1/4W 5% 10k LL R55 R68
2 024965 RES CF 1/4W 5% 1k LL R60 R75
7 025069 RES CF 1/4W 5% 1M LL R53-54 R67 R71-73 R77
2 025059 RES CF 1/4W 5% 220k LL R58-59
1 024987 RES CF 1/4W 5% 22k LL R78
1 024989 RES CF 1/4W 5% 33k LL R48
1 028948 RES CF 1/4W 5% 6.2k LL R76
4 024980 RES CF 1/4W 5% 8.2k LL R50 R52 R64 R66
PARTS LIST
EFFECTS PCB ASSEMBLY (CONT)
QTY PART # DESCRIPTION REFERENCE DESIGNATION
1 028091 SWITCH PUSH SLFLK SHORT STROKE S2
1 048451 BUTTON PUSH OFF WHITE @S2
1 041465 XSTR N-CH JFET J113 TO-92 Q3
1 016739 XSTR NPN 2N4401 TO-92 Q2
CHASSIS ASSEMBLY
1 051432 PCB ASSY MAIN PCB SUNN MODEL T
1 053964 PCB ASSY FX LOOP SUNN MODEL T
2 028069 BUSHING SNAP 3/4x1-1/8 WHT @ PWR XFMR
1 018022 BUSHING SNAP 5/16x17/32 BLK @ CHOKE
2 012560 BUSHING SNAP 5/8x27/32 BLK @ OUTPUT XFMR
1 051425 CHASSIS SUNN MODEL T
1 036486 CHOKE CHOKE L1
1 032219 COLLAR-PILOT LIGHT @ PILOT LIGHT
1 047213 CONN. AC LINE MALE IEC IEC PWR JACK
1 053892 COVER BOX BIAS CONTROLS
4 026730 DIODE 1N4006 800V LL @ V7 V8 V9 V10
1 051439 FRONT PANEL SUNN MODEL T
036702 FUSE HOLDER 3AG FINGER GRIP @ LINE FUSE F1
013737 FUSE TD 1-1/4x1/4" 250V 4A LINE FUSE F1 (120V/100V UNITS)
013115 FUSE TD 20mm x 5mm 250V 2A LINE FUSE F1 (230V/240V UNITS)
036703 FUSE HOLDER 5mm FINGER GRIP @ V7-V10 PROTECT, @ F1 (230V/240V).
013004 FUSE 100mA TIME 5mm V7-V10 PROTECT F2 F3
14 024604 KNOB BLACK W/WHITE STAMP 1-10 @ ALL CONTROLS
1 021741 HOLDER DIAL LITE ASSY PILOT @ PILOT LIGHT
1 026471 JACK XLR MALE PANEL MOUNT XLR LINE OUT
1 021550 JACK PHONE TIP SHUNT 12A MAIN SPKR JACK J8
1 021956 JACK PHONE OPEN CKT 11 EXT. SPKR JACK J9
1 025718 JEWEL PILOT LITE RED #20 @ PILOT LIGHT
1 031625 NUT 1/16-27 HOLDER PILOT LIGHT @ PILOT LIGHT
4 028272 NUT KEP 1/4x20 FOJ @ PWR XFMR
4 022004 NUT KEPS #8-32 ZINC @ OUTPUT XFMR
