Sunn Model T - Channel Select and Presence

PARTS LIST
CHASSIS ASSEMBLY (CONT)
QTY PART # DESCRIPTION REFERENCE DESIGNATION
2 097360 NUT HEX 4-40 EX LOCK @ IEC PWR JACK
2 016352 NUT HEX 3/8-32 x 3/32 TK NI @ SPKR JACKS J8 J9
1 021642 PILOT LIGHT #T47 @ PILOT LIGHT
4 024969 RES CF 1/4W 5% 1.5K LL @ V7 V8 V9 V10
2 014172 SCREW M 4-40 x 1/4" PHP BLX @ IEC PWR JACK
2 026521 SCREW SMB 8 x 3/8" RH PHS BLK @ XLR LINE OUT
2 021568 SCREW M 6-32 x 3/16" PHP NI @ IMPED. SELECTOR
4 026553 SCREW M 8-32 x 3/8" PHP BLX @ OUTPUT XFMR
4 026501 SCREW C 1/4-20x1/2" HH BLX @ PWR XFMR
2 014999 SCREW M 6-32x1/4 PHP BLX @ BK1 BK2
16 032806 SCREW TF 6-32x1/4" PHP BLX @ CHOKE , SOCKETS, COVER BOX
2 038900 SCREW TF 6-32x1/4" PHP ZI @ CHASSIS GNDS
25 031184 SCREW M 6-32x1/4 PHP BLX ITLW @ STANDOFFS
1 036570 SWITCH TOGGLE DPST W/NUTS PWR SWITCH
1 026472 SWITCH SLIDE DPTT IMPED. SELECTOR
1 051855 SWITCH ROCKER DPST W/BEZEL SUNN STANDBY SWTCH
2 023572 TUBE 7025/12AX7A CHINESE V1 V2
4 013341 TUBE 7025/12AX7WA RUSSIAN MADE V3 V4 V5 V6
4 053980 TUBE 6L6GC SVETLANA V7 V8 V9 V10
4 023580 TUBE SOCKET 8 PIN @ V7 V8 V9 V10
2 023606 TUBE SOCKET 9 PIN @ V5 V6
4 020424 TUBE RING UNIVERSAL (277H-2) @ V7 V8 V9 V10
2 023598 TUBE SHIELD V5 V6
4 053893 TUBE SHIELD MODEL T V1 V2 V3 V4
2 022293 WSHR FLAT .473x.750 NI @ PWR SWTCH & ARENA/CLUB SWTCH
8 022319 WSHR FLT 1/4x9/16 NI @ PWR XFMR
2 031153 WSHR FLAT 3/8 x .614" NI @ SPKR JACKS J8 J9
2 016436 WSHR LCK INTL 3/8 x .687 x .035 NI @ SPKR JACKS J8 J9
2 026564 WSHR FLAT .284x1/2 ZI @ R139 R141
5 028501 WSHR FLAT .477x.625 NI @ J2-J6 FX BOARD JACKS
1 026478 XFMR OUTPUT 100W 4,8,16 OHMS OUTPUT XFMR T2
1 051463 XFMR POWER SUNN MODEL T PWR XFMR T1
PARTS LIST
CAB ASSEMBLY
QTY PART # DESCRIPTION REFERENCE DESIGNATION
8 029071 CORNER NOTCHED NICKEL (FD)
4 051049 FOOT RUBBER 1.5 DIA
2 027846 HANDLE 9.25" NO LOGO
4 019279 HANDLE CAP 2 HOLE NICKEL
2 032524 INSERT HANDLE
8 021972 NUT T 10-32x3/4 STR 3 PRNG BLX
16 026571 SCRW SMAB 8x5/8 THP NI
4 026625 SCRW WOOD 8x1 FH
8 031344 SCRW SMA 10x3/4 OHP NI
.012 027648 TAPE ALUM 6"x60 YDS
1.05 051343 VINYL TOLEX 4227A
UNIT ASSEMBLY
1 053861 CABINET ASSY MODEL T
051426 CHASSIS ASSY. 120V DOM.
051428 CHASSIS ASSY. 240V AUST.
051427 CHASSIS ASSY. 230V
051429 CHASSIS ASSY. 100V JAP.
047248 CORD PWR W/IEC CONN DOM
047250 CORD PWR W/IEC CONN 240V AUST
047249 CORD PWR W/IEC CONN 240V UK
047251 CORD PWR W/IEC CONN 230V EUR
053997 CORD PWR W/IEC CONN 100V JAP
1 053584 FOOTSWITCH ASSY 2 BUTTON SUNN
1 051437 GRILLE FRONT SUNN MODEL T
1 051438 GRILLE REAR SUNN MODEL T
1 051380 NAME PLATE SUNN @ FRONT GRILLE
4 097360 NUT HEX 4-40 EXT LOCK @ SUNN LOGO
4 014171 SCRW M 4-40x3/8 PHP BLX @ SUNN LOGO
8 036112 SCRW SMAB 6-32x1-1/4 OHP BLX W/WS @ GRILLES
4 9904101550 SCREW M 8-32x1-1/4 OHP BLX WX @ CAB TO CHASS
4 029527 WSHR FNSH 8-5/8 FLNGD BLX WX @ CAB TO CHASS
5
