PARTS LIST
FOOTSWITCH ASSEMBLY
QTY PART # DESCRIPTION REFERENCE DESIGNATION
1 028448 PCB ASSY FT SW 2 BUTTON
1 028107 HSG FTSW 2 BUTTON
1 053585 TOP PLATE
1 028109 HSG END CUP LEFT FTSW
1 028143 HSG END CUP RIGHT FTSW
8 028684 SCRW SMB 6x3/8 PH PHS BLX
1 028895 CABLE ASSY FTSW RT ANG 12'
2 031899 WSHR NYL .485x.775x.150 TK
1 031647 NUT HEX 12mmx1mm NI
6
