Sunn T50C
CHASSIS ASSEMBLY (cont)
QTY PART # DESCRIPTION REFERENCE DESIGNATION
Ref 0036703000 FUSE HOLDER 5mm FINGER GRIP @ V8-9 PROTECT, @ F1 EXP.
1 0013004000 FUSE 100mA TIME 5mm V8-9 PROTECT F2
1 0021550000 JACK PHONE TIP SHUNT 12A MAIN SPKR JACK J8
1 0021956000 JACK PHONE OPEN CKT 11 EXT. SPKR JACK J9
1 0055362000 CHASSIS SUNN T50C
1 0053892000 COVER BOX BIAS CONTROLS
2 0023572000 TUBE 7025/12AX7A CHINESE V1 V2
1 0023531010 TUBE 12AT7 CHINESE V5
5 0013341000 TUBE 7025/12AX7WA RUSSIAN MADE V3 V4 V6 V7 V8
2 0053980000 TUBE 6L6GC SVETLANA V9 V10
3 0023598000 TUBE SHIELD @V6 V7 V8
5 0053893000 TUBE SHIELD MODEL T @V1 V2 V3 V4 V5
2 0023580000 TUBE SOCKET 8 PIN @ V7 V8 V9 V10
2 0020424000 TUBE RING UNIVERSAL (277H-2) @ V7 V8 V9 V10
3 0023606000 TUBE SOCKET 9 PIN @ V5 V6 V10
15 0024604000 KNOB BLACK W/WHITE STAMP 1-10 @ ALL CONTROLS
2 0024969001 RES CF 1/4W 5% 1.5K LL @ V9 V10
2 0026730001 DIODE 1N4006 800V LL @ V9 V10
2 0022293000 WSHR FLAT .473x.750 NI @ PWR SWTCH & ARENA/CLUB SWTCH
4 0026501000 SCREW C 1/4-20x1/2" HH BLX @ PWR XFMR
4 0028272000 NUT KEP 1/4x20 FOJ @ PWR XFMR
8 0022319000 WSHR FLT 1/4x9/16 NI @ PWR XFMR
Ref 0047163000 TUBING SHRINK 1" BLACK @ PWR XFMR PRI. LEADS
4 0026553000 SCREW M 8-32 x 3/8" PHP BLX @ OUTPUT XFMR
4 0022004000 NUT KEPS #8-32 ZINC @ OUTPUT XFMR
2 0097360000 NUT HEX 4-40 EX LOCK @ IEC PWR JACK
2 0014172000 SCREW M 4-40 x 1/4" PHP BLX @ IEC PWR JACK
2 0031153000 WSHR FLAT 3/8 x .614" NI @ SPKR JACKS J8 J9
2 0016436000 WSHR LCK INTL 3/8 x .687 x .035 NI @ SPKR JACKS J8 J9
2 0016352000 NUT HEX 3/8-32 x 3/32 TK NI @ SPKR JACKS J8 J9
2 0021568000 SCREW M 6-32 x 3/16" PHP NI @ IMPED. SELECTOR
2 0014999000 SCREW M 6-32x1/4 PHP BLX @ BK1 BK2 BIAS BOARD
2 0026564000 WSHR FLAT .284x1/2 ZI @ BIAS AND BALANCE
16 0032806000 SCREW TF 6-32x1/4" PHP BLX @ CHOKE , SOCKETS, COVER BOX
2 0038900000 SCREW TF 6-32x1/4" PHP ZI @ CHASSIS GNDS
24 0031184000 SCREW M 6-32x1/4 PHP BLX ITLW @ STANDOFFS
5 0053479000 NUT HEX 7/16 20 x 1/8 NI @ FX BOARD JACKS
5 0053480000 WSHR FLAT .442x.692 NI @ FX BOARD JACKS
Ref 0012398000 TUBING SHRINK 3/16 BLACK @ PILOT LIGHT WIRES
1 0055365000 PCB ASSY MAIN PCB T50C
1 0055810000 PCB ASSY FX LOOP T50C
1 0055372000 FRONT PANEL SUNN T50C
1 0049009000 XFMR OUTPUT PROSONIC OUTPUT XFMR T2
1 0055358000 XFMR POWER T50C
1 0037099000 XFMR OUTPUT DUAL 12AT7 TO REVERB REVERB XFMR
1 0036486000 CHOKE CHOKE L1
