Sunn T50C
CAB ASSEMBLY
QTY PART # DESCRIPTION REFERENCE DESIGNATION
8 0002971000 CORNER NOTCHED NI
1 0027846000 HANDLE 9.25" NO LOGO
1 0032524000 INSERT HANDLE
2 0019279000 HANDLE CAP 2 HOLE NI
4 0051049000 FOOT RUBBER
8 0022244000 SCREW M10-32 x 1 1/8 OHP NI
16 0026571000 SCREW SMAB 8x5/8 THP NI
12 0021972000 NUT T 10-32 X 3/4 STR 3 PRNG BLX
4 0023505000 MTG PLATE SWIVEL CASTER
16 0027199000 SCREW SMAB 10 X 3/4 PHP NI
Ref 0055366000 GRL CLTH FRM 1/2" PB
Ref 0037788000 GRL CLTH BLK/SILVER
Ref 0027648000 TAPE ALUM 6" X 60 YDS
ref 0051343000 VINYL TOLEX
ref 0029085000 VELCRO STRIP LOOP 1.5 BCK
ref 0029086000 VELCRO STRIP HOOK 1.5" WD BLK
FOOTSWITCH ASSEMBLY
QTY PART # DESCRIPTION REFERENCE DESIGNATION
1 0028895000 CABLE ASSY FTSW RT ANG 12'
3 0006260001 DIODE 1N4448 SIGNAL
1 0031017000 DIODE ZEN 1N5223B 2.7V 5%
3 0028039000 LED RED 5x5mm SLB-55VR3
1 0028109000 HSG END CUP LEFT FTSW
1 0028141000 HSG FTSW 3 BUTTON
1 0028143000 HSG END CUP RIGHT FTSW
1 0037036000 JACK PCB MONO CA (099-0912-000)
1 0053898000 PCB FAB FTSW 3 BTN SUNN BASS
1 0055593000 PCB ASSY FTSW 3 BTN DSP/T50C
1 0055770000 PLATE FTSW 3 BTTN SUNN T50C
3 0028714000 SWITCH PUSH SPDT
8 0028684000 SCRW SMB 6x3/8 PH PHS BLX
1 0031647000 NUT HEX 12mmx1mm NI @ JACK
3 0031899000 WSHR NYL .485x.775x.150 TK
3 0034921000 SPACER RND NYL .147x.250x.780
END ITEM ASSEMBLY
QTY PART # DESCRIPTION REFERENCE DESIGNATION
1 0055361000 CABINET ASSY T50C
1 0051363000 CHASSIS ASSY. 120V DOM.
1 0051370000 CHASSIS ASSY. 240V AUST.
1 0051369000 CHASSIS ASSY. 230V
