Panels
Panel List
Panels NumbersSize
6
Top Board（×1）
915*295*25mm
4
3
Side Boards（×2）
1480*294*25mm
77
Back Boards（×2）
1484*435*5mm
8 8 8
Movable Shelf Panels（×3）
862*272*18mm
1
Bottom Board（×1）
863*273*18mm
2
Base Panel（×1）
70*863*18mm
5
Fixed Shelf Panel（×1）862*273*8mm
01 02
2
Keep all parts out of the children’s reach.
WARNING
You need to have a crosshead screwdriver beforehand.
Place all the panels on a clean and smooth surface, such as a rug or
carpet, to prevent them from being scratched.
Don’t tighten screws or bolts until all the pieces are fitted.
It is recommended to have 2 persons to complete the assembly.
If you have any issue regarding the product, please contact us at
ecservice@isunon.com.
Make sure that all parts in your product package, including panels and
accessories, match up with those listed in the Panels & Accessories list.
NOTE
CONTACT US
crosshead screwdriver
Not included in package.
NOTE
In case of any doubts,contact Sunon.
3
Handle with care,protective layer is required.
2
Safe carriage,multi-people are needed.
1
Assembly Manual
