SUNON Five-layer Open Bookcase - Assembly Instructions; Accessories List and Component Details; Step 2: Attach Bottom Board and Fixed Panel to Side Panels

Assembly Instructions
Accessories List
Three-in-one Connector
15*32mm
A
（×13+1）
Three-in-one Connector
15*32mm
A
（×1）
Three-in-one Connector
15*32mm
A
A
C
（×8）
Pan Head Self Tapping
Screw
M3*16mm
D
（×12+1）
Back-board Slot
/
G
1
（×1）
Adjusting Pin
M8*21mm
E
（×4）
Shelf Support
5*15mm
F
（×12）
Three-in-one Connector
Cover
17.8*4.5mm
B
（×13+1）
Dowel
8*40mm
C
（×13+1）
Wood Pin
8*40mm
C
（×10）
Step 1：
Fit and fasten the Base Panel on the Bottom Board.
Step 2：
Fit and fasten the Bottom Board and fixed Panel with two Side Panels.
03
04
4
3
5
1
2
2
Assembly Manual
