Sunsystem SWP 2N 300 - SWP N Model Specifications

ТЕХНИЧЕСКИ ПАСПОРТ. ИНСТРУКЦИЯ за МОНТАЖ и ЕКСПЛОАТАЦИЯ
ТЕХНИЧЕСКИ ПАСПОРТ. ИНСТРУКЦИЯ за МОНТАЖ и ЕКСПЛОАТАЦИЯ
17
INSTALLATION and OPERATION MANUAL
INSTALLATION and OPERATION MANUAL
SWP N
150
SWP N
200
SWP N
300
SWP N
400
SWP N
500
Capacity L 150 200 300 400 500
Height mm 1070 1340 1420 1470 1720
Diameter D,mm Ø 560 Ø 560 Ø 650 Ø750 Ø750
Insulaon 50 mm rigid PU
Operangpressure/Maximumtemperature bar/
0
C 10/95 10/95 10/95 10/95 10/95
Test pressure bar 15 15 15 15 15
Electricheang(oponal) кW 1 x (3) 1 x (3) 1 x (4.5) 1 x (6) 1x(7.5)
Weight kg 70 90 121 165 190
Cold water inlet A,mm Rp1”/182 Rp1”/182 Rp1”/215 Rp1
1/4 “
/270 Rp1
1/2”
/270
Hot water outlet B,mm Rp1”/895 Rp1”/1160 Rp1”/1182 Rp1
1/4 ”
/1240 Rp1
1/2”
/1453
Recirculaon R,mm,Rp
3/4”
Rp
3/4”
/652 Rp
3/4”
/922 Rp
3/4”
/1007 Rp1”/1105 Rp1”/1206
Operangpressure/
Maximum temperature coils S1
bar/
0
C 16/110 16/110 16/110 16/110 16/110
Test pressure coils S1 bar 25 25 25 25 25
Coils capacity S1 L 8.6 11.7 14.8 17.2 20
Coils Heat exchange surface S1 m
2
1.4 1.9 2.3 2.8 3.3
Inlet/Outlet Lower coi S1 S1i/S1o,
mm,Rp1”
872/182 1122/182 1155/215 1210/270 1350/270
Prolongedpoweracc.toDIN4708;
10°C/80°C/45°C,S1
kW (m3/h) 40.4(0.99) 51(1.25) 62(1.52) 75(1.84) 84(2.06)
NL-powercoecientat60°C,S1 NL 60°C 6 8 20 27 34
PressuredropΔp,S1 Δp,mbar 120 150 400 600 710
Inspeconopening/ange O,Ø,mm Ø110x180/
309
Ø110x180/
309
Ø110x180/
320
Ø110x180/
450
Ø110x180/
450
Sleeve for Electric element
oninspeconopeningange
Uo,mm,Rp1
1/2”
309 309 320 450 450
Drain sleeve Y,mm,Rp1” 30 30 30 30 30
Anode P,mm,Rp1
1/4”
1070 1340 1410 1318 1568
Addionalsensorsleeve Z1/Z2/Z3,
mm,Rp
1/2”
410/-/
868
410/650/
1138
430/700/
1170
565/720/
1204
560/800/
1453
Air vent sleeve F,mm,Rp1” 1070 1340 1410 1460 1710
Sensor sleeve for thermostat G,mm,Rp1/2” 697 967 1054 1054 1206
