Sunsystem SWP 2N 300 - SWP 2 N Model Specifications

ТЕХНИЧЕСКИ ПАСПОРТ. ИНСТРУКЦИЯ за МОНТАЖ и ЕКСПЛОАТАЦИЯ
ТЕХНИЧЕСКИ ПАСПОРТ. ИНСТРУКЦИЯ за МОНТАЖ и ЕКСПЛОАТАЦИЯ
19
INSTALLATION and OPERATION MANUAL
INSTALLATION and OPERATION MANUAL
SWP 2N
300
SWP 2N
400
SWP 2N
500
Capacity L 300 400 500
Height mm 1420 1490 1720
Diameter D,mm Ø 660 Ø750 Ø750
Insulaon 50 mm rigid PU
Operangpressure/Maximumtemperature bar/
0
C 10/95 10/95 10/95
Test pressure bar 15 15 15
Electricheang(oponal) кW 1 x (4.5) 1 x (6) 1x(7.5)
Weight kg 145 198 236
Cold water inlet A,mm Rp1”/215 Rp
1/4 “
/240 Rp1
1/2”
/240
Hot water outlet B,mm Rp1”/1185 Rp
1/4 ”
/1240 Rp1
1/2”
/1475
Recirculaon R,mm,Rp
3/4”
Rp
3/4”
/1007 Rp1”/1105 Rp1”/1206
Operangpressure/MaximumtemperaturecoilsS1/S2 bar/
0
C 16/110 16/110 16/110
Test pressure coils S1/S2 bar 25 25 25
Coils capacity S1 /S2 L 6.5/16.1 10/18.9 11.8/26
Coils Heat exchange surface S1/S2 m
2
1.2/2.7 1.5/3.2 1.8/4.36
Inlet/Outlet Lower coi S1 S1i/S1o,mm,Rp
3/4”
435/215 562/240 606/240
Inlet/Outlet Upper coi S2 S2i/S2o,mm,Rp
3/4”
1105/587 1195/665 1446/726
Prolongedpoweracc.toDIN4708;
10°C/80°C/45°C,S1/S2
kW (m3/h) 53(1.30)/
75(1.84)
62(1.52)/
82(2.01)
72(1.77)/
94(2.31)
NL-powercoecientat60°C,S1/S2 NL 60°C 11/17 14/22 18/29
PressuredropΔp,S1/S2 Δp,mbar 55/70 70/85 90/120
Inspeconopening/ange O,Ø,mm Ø110x180/
545
Ø110x180/
620
Ø110x180/
666
SleeveforElectricelementoninspeconopeningange Uo,mm,Rp1
1/2”
545 620 666
Drain sleeve Y,mm,Rp1” 30 30 30
Anode P,mm,Rp1
1/4”
1410 1318 1575
Addionalsensorsleeve Z1/Z2/Z3,mm,Rp1
1/2”
325/697/1170 380/755/1155 380/858/1455
Air vent sleeve F,mm,Rp1” 1410 1480 1710
Sensor sleeve for thermostat G,mm,Rp1/2” 1095 1145 1453
