2 Installation instructions
2.1 Electrical connection
Before the display can be wall- or panel-mounted, the
electrical connection must be established. Afterwards
the display is mounted in a clearly visible location,
using the enclosed screws.
Please pay attention and mount the device in a
location that is protected from direct humidity.
The FOX-D1, FOX-D1/E can be used for 12V and
24V battery systems.
The FOX-D1 is connected to the other components of
the solar installation by means of the cables.
Please select the application most suitable for your
type of application from the following cabling
examples.
Please always observe the correct polarity of the
cables.
