2.5 Cabling example third-party controller
The universal digital display FOX-D1 can be
combined with all commercially available solar charge
controllers.
The connection of charge controllers with only
overload protection is carried out according to the
cabling example: FOX-100.
If the charge controller to be connected also has a
total discharge protection, the connection is carried
out according to the cabling example FOX-220.:
Display of battery voltage and
charge/ discharge current display
EN
16
