Sunx FX-301 - Page 41

108
FX-301
DIMENSIONS (Unit: mm in)
Main cable (Optional)
CN-73-C1 CN-73-C2
CN-73-C5
Sub cable (Optional)
CN-71-C1 CN-71-C2
CN-71-C5
Amplifier mounting bracket (Optional)
MS-DIN-2
End plate (Optional)
MS-DIN-E
Model No.
CN-71-C1
CN-71-C2
CN-71-C5
Length (mm in)
1,000 39.370
2,000 78.740
5,000 196.850
• Length (L)
Model No.
CN-73-C1
CN-73-C2
CN-73-C5
Length (mm in)
1,000 39.370
2,000 78.740
5,000 196.850
• Length (L)
Amplifier
FX-301
FX-301P
Material: Cold rolled carbon steel (SPCC)
(Uni-chrome plated)
Material: Polycarbonate
