FRONT AIR INTAKE CHIN — A — Figure 3/4
The ow of incoming air in the front part of the helmet (chin)
may be regulated by adjusting on the middle part of the air intake:
- Figure 3: air intake closed.
- Figure 4: air intake fully open.
FRONT AIR INTAKE UPPER — B — Figure 5/6
The ow of incoming air in the upper front part of the helmet
may be regulated by adjusting the middle part of the air intake:
- Figure 5: air intake closed.
- Figure 6: air intake fully open.
FIGURE 3
A
FIGURE 4
FIGURE 5
FIGURE 6
A
