Glider user's manual | STEP
SUPAIR | STEP | page 19
Maintenance sheet
Size XS
Line Check Maintenance Sheet
Tolerance: 10 mm.
Measurements made from the base of the lines to the base of the wing, WITHOUT risers and Maillons Rapides, were under 5 kg.
Risers length,
Measured wit-
hout carabiner.
Carabiners len-
ght : 29 mm.
Tolérance +/- 5mm
A B C D Frein
Manual Tested
sample
Diff Manual Tested
sample
Diff Manual Tested
sample
Diff Manual Tested
sample
Diff Manual Tested
sample
Diff
Center
1 6230 6235 5 6148 6152 4 6283 6276 -7 6338 6329 -9 7105 7109 4
2 6145 6153 8 6063 6062 -1 6194 6190 -4 6248 6240 -8 6871 6872 1
3 6176 6179 3 6094 6091 -3 6218 6218 0 6268 6261 -7 6683 6681 -2
4 6120 6124 4 6037 6035 -2 6150 6149 -1 6196 6191 -5 6587 6585 -2
5 6009 6007 -2 5930 5934 4 6035 6031 -4 6077 6072 -5 6412 6409 -3
6 6011 6009 -2 5935 5936 1 6029 6020 -9 6066 6060 -6 6270 6267 -3
7 5876 5880 4 5824 5822 -2 5895 5887 -8 6212 6209 -3
8 5743 5736 -7 5708 5706 -2 5771 5766 -5 6242 6249 7
9 5684 5686 2 5674 5668 -6 5725 5731 6 6106 6103 -3
10 6058 6054 -4
Stabilizers
11 5402 5393 -9 5380 5371 -9 5425 5419 -6 6028 6028 0
Wingtip
12 5292 5298 6 5316 5309 -7 5371 5364 -7
RISERS Non accéléré Accéléré
Manual Tested
sample
Diff Manual Tested
sample
Diff
A
475 475 0 345 345 0
A'
475 474 -1 345 344 -1
B
475 473 -2 388 385 -3
C
475 476 1 475 476 1
RISERS Non accéléré Accéléré
Manual Tested
sample
Diff Manual Tested
sample
Diff
A
505 505 0 375 375 0
A'
505 504 -1 375 374 -1
B
505 503 -2 418 415 -3
C
505 506 1 505 506 1
Risers length,
Measured with
carabiner.
Tolérance +/- 5mm
STEP size XS
