Lines individual lenghts
A LINES B LINES C LINES D LINES BRAKE LINES
NAME CUT SEWN NAME CUT SEWN NAME CUT SEWN NAME CUT SEWN NAME CUT SEWN
AR1 3969 4219 BR1 3921 4171 CR1 4026 4276 d1 501 701 BRML 1250 1450
AR2 4186 4436 BR2 4125 4375 CR2 4215 4465 d2 486 686 BRmain 1459 1459
AR3 4299 4549 BR3 4279 4529 CR3 4345 4595 d3 486 686 BRM1 1701 1901
a1 2273 2473 b1 2241 2441 CM1 1837 2037 d4 431 631 BRM2 2030 2230
a2 2188 2388 b2 2156 2356 CM2 1762 1962 d5 406 606 BRM3 2504 2704
a3 2219 2419 b3 2187 2387 CM3 1782 1982 d6 397 597 BRMU1 1604 1804
a4 1939 2139 b4 1918 2118 CM4 1571 1771 BRMU2 1346 1546
a5 1828 2028 b5 1811 2011 CM5 1477 1677 BRMU3 892 1092
a6 1830 2030 b6 1816 2016 CM6 1475 1675 BRMU4 913 1113
a7 1584 1784 b7 1551 1751 c1 448 648
STABILO LINES
br1 1288 1488
a8 1451 1651 b8 1435 1635 c2 434 634
NAME CUT SEWN
br2 1054 1254
a9 1387 1587 b9 1396 1596 c3 438 638 STMain 4253 4453 br3 1124 1324
a10 385 585 b10 363 563 c4 387 587 STRis 305 505 br4 1028 1228
c5 366 566 STMA 471 671 br5 978 1178
c6 362 562 STMB 488 688 br6 836 1036
c7 1552 1752 sta 273 473 br7 757 957
c8 1428 1628 stb 280 480 br8 787 987
c9 1382 1582 stc 335 535 br9 1087 1287
c10 391 591 br10 1039 1239
br11 1009 1209
