SUPAIR Step - Lines Individual Lengths (Page 22)

Glider user's manual | STEP
SUPAIR | STEP | page 22
Maintenance sheet
STEP size S
Lines individual lenghts
A LINES B LINES C LINES D LINES BRAKE LINES
NAME CUT SEWN NAME CUT SEWN NAME CUT SEWN NAME CUT SEWN NAME CUT SEWN
AR1 4464 4214 BR1 4409 4159 CR1 4523 4273 d1 734 534 BRML 1543 1343
AR2 4697 4447 BR2 4636 4386 CR2 4736 4486 d2 718 518 BRmain 1463 1463
AR3 4820 4570 BR3 4795 4545 CR3 4879 4629 d3 718 518 BRM1 2023 1823
a1 2608 2408 b1 2577 2377 CM1 2147 1947 d4 657 457 BRM2 2385 2185
a2 2520 2320 b2 2488 2288 CM2 2069 1869 d5 632 432 BRM3 2899 2699
a3 2555 2355 b3 2522 2322 CM3 2092 1892 d6 622 422 BRMU1 1914 1714
a4 2261 2061 b4 2236 2036 CM4 1866 1666 BRMU2 1646 1446
a5 2144 1944 b5 2124 1924 CM5 1767 1567 BRMU3 1158 958
a6 2147 1947 b6 2129 1929 CM6 1765 1565 BRMU4 1181 981
a7 1883 1683 b7 1855 1655 c1 678 478
STABILO LINES
br1 1578 1378
a8 1742 1542 b8 1732 1532 c2 663 463
NAME CUT SEWN
br2 1335 1135
a9 1675 1475 b9 1691 1491 c3 667 467 STMain 4774 4574 br3 1405 1205
a10 604 404 b10 581 381 c4 611 411 STRis 505 305 br4 1306 1106
c5 589 389 STMA 715 515 br5 1248 1048
c6 585 385 STMB 720 520 br6 1101 901
c7 1843 1643 sta 492 292 br7 1015 815
c8 1712 1512 stb 507 307 br8 1049 849
c9 1680 1480 stc 564 364 br9 1371 1171
c10 624 424 br10 1322 1122
br11 1289 1089
