SUPAIR Step - Line Check Maintenance Sheet (Page 23)

Glider user's manual | STEP
SUPAIR | STEP | page 23
Size M
Line Check Maintenance Sheet
Maintenance sheet
STEP size M
Tolerance: 10 mm.
Measurements made from the base of the lines to the base of the wing, WITHOUT risers and Maillons Rapides, were under 5 kg.
Risers length,
Measured wit-
hout carabiner.
Carabiners len-
ght : 29 mm.
Tolérance +/- 5mm
A B C D Frein
Manual Tested
sample
Diff Manual Tested
sample
Diff Manual Tested
sample
Diff Manual Tested
sample
Diff Manual Tested
sample
Diff
Center
1
6893 6897 4 6797 6802 5 6951 6951 0 7012 7005 -7 7890 7896 6
2
6803 6805 2 6707 6708 1 6856 6852 -4 6915 6910 -5 7641 7647 6
3
6840 6844 4 6743 6740 -3 6885 6881 -4 6940 6932 -8 7427 7421 -6
4
6784 6788 4 6691 6692 1 6817 6812 -5 6868 6864 -4 7325 7320 -5
5
6663 6668 5 6575 6573 -2 6692 6684 -8 6738 6730 -8 7136 7135 -1
6
6666 6667 1 6581 6574 -7 6686 6681 -5 6726 6717 -9 6983 6984 1
7
6516 6516 0 6459 6461 2 6530 6523 -7 6916 6915 -1
8
6369 6369 0 6331 6332 1 6394 6391 -3 6950 6951 1
9
6304 6310 6 6292 6289 -3 6360 6352 -8 6804 6805 1
10
6756 6749 -7
Stabilizers
11
6041 6035 -6 6017 6010 -7 6067 6064 -3 6722 6719 -3
Wingtip
12
5921 5926 5 5947 5940 -7 6007 6002 -5
RISERS Non accéléré Accéléré
Manual Tested
sample
Diff Manual Tested
sample
Diff
A
490 494 4 330 327 -3
A'
490 492 2 330 325 -5
B
490 493 3 380 380 0
C
490 494 4 490 494 4
RISERS Non accéléré Accéléré
Manual Tested
sample
Diff Manual Tested
sample
Diff
A
520 524 4 360 357 -3
A'
520 522 2 360 355 -5
B
520 523 3 410 410 0
C
520 524 4 520 524 4
Risers length,
Measured with
carabiner.
Tolérance +/- 5mm
