Maintenance sheet
STEP size M
Lines individual lenghts
A LINES B LINES C LINES D LINES BRAKE LINES
NAME CUT SEWN NAME CUT SEWN NAME CUT SEWN NAME CUT SEWN NAME CUT SEWN
AR1 4651 4401 BR1 4592 4342 CR1 4716 4466 d1 755 555 BRML 1615 1415
AR2 4898 4648 BR2 4832 4582 CR2 4936 4686 d2 738 538 BRmain 1474 1474
AR3 5021 4771 BR3 4997 4747 CR3 5074 4824 d3 739 539 BRM1 2116 1916
a1 2714 2514 b1 2679 2479 CM1 2231 2031 d4 677 477 BRM2 2503 2303
a2 2624 2424 b2 2589 2389 CM2 2151 1951 d5 649 449 BRM3 3039 2839
a3 2661 2461 b3 2625 2425 CM3 2175 1975 d6 639 439 BRMU1 2009 1809
a4 2351 2151 b4 2325 2125 CM4 1939 1739 BRMU2 1722 1522
a5 2230 2030 b5 2209 2009 CM5 1837 1637 BRMU3 1209 1009
a6 2233 2033 b6 2215 2015 CM6 1835 1635 BRMU4 1232 1032
a7 1962 1762 b7 1928 1728 c1 696 496 STABILO LINES br1 1643 1443
a8 1815 1615 b8 1800 1600 c2 681 481 NAME CUT SEWN br2 1394 1194
a9 1745 1545 b9 1756 1556 c3 686 486 STMain 5001 4801 br3 1467 1267
a10 629 429 b10 605 405 c4 628 428 STRis 505 305 br4 1365 1165
c5 605 405 STMA 724 524 br5 1302 1102
c6 601 401 STMB 744 544 br6 1149 949
c7 1921 1721 sta 507 307 br7 1059 859
c8 1785 1585 stb 513 313 br8 1093 893
c9 1751 1551 stc 573 373 br9 1440 1240
c10 635 435 br10 1392 1192
c10 635 435 br11 1358 1158
br11 1358 1158
