SUPAIR Step - Line Check Maintenance Sheet (Page 25)

Glider user's manual | STEP
SUPAIR | STEP | page 25
Size ML
Line Check Maintenance Sheet
Maintenance sheet
STEP size ML
Tolerance: 10 mm.
Measurements made from the base of the lines to the base of the wing, WITHOUT risers and Maillons Rapides, were under 5 kg.
Risers length,
Measured wit-
hout carabiner.
Carabiners len-
ght : 29 mm.
Tolérance +/- 5mm
A B C D Frein
Manual Tested
sample
Diff Manual Tested
sample
Diff Manual Tested
sample
Diff Manual Tested
sample
Diff Manual Tested
sample
Diff
Center
1 7176 7182 6 7074 7082 8 7241 7235 -6 7304 7298 -6 8143 8139 -4
2 7084 7088 4 6982 6989 7 7144 7137 -7 7205 7202 -3 7887 7887 0
3 7123 7131 8 7020 7024 4 7174 7168 -6 7225 7216 -9 7679 7678 -1
4 7067 7075 8 6972 6977 5 7103 7095 -8 7155 7147 -8 7574 7577 3
5 6942 6947 5 6852 6858 6 6973 6970 -3 7021 7017 -4 7379 7376 -3
6 6945 6949 4 6858 6859 1 6967 6969 2 7009 7011 2 7220 7225 5
7 6795 6799 4 6736 6738 1 6803 6808 5 7151 7154 3
8 6642 6640 2 6603 6604 1 6662 6666 4 7185 7186 1
9 6574 6576 2 6563 6561 -2 6626 6630 4 7037 7035 -2
10 6985 6979 -6
Stabilizers
11 6294 6288 -6 6269 6266 -3 6321 6320 -1 6953 6949 -4
Wingtip
12 6169 6177 8 6196 6201 5 6258 6256 -2
RISERS Non accéléré Accéléré
Manual Tested
sample
Diff Manual Tested
sample
Diff
A
515 515 0 360 361 1
A'
515 513 -2 360 361 1
B
515 514 -1 412 410 -2
C
515 514 -1 515 514 -1
RISERS Non accéléré Accéléré
Manual Tested
sample
Diff Manual Tested
sample
Diff
A
545 545 0 390 391 1
A'
545 543 -2 390 391 1
B
545 544 -1 442 440 -2
C
545 544 -1 545 544 -1
Risers length,
Measured with
carabiner.
Tolérance +/- 5mm
