SUPAIR Step - Line Check Maintenance Sheet (Page 27)

Glider user's manual | STEP
SUPAIR | STEP | page 27
Size L
Line Check Maintenance Sheet
Maintenance sheet
STEP size L
Tolerance: 10 mm.
Measurements made from the base of the lines to the base of the wing, WITHOUT risers and Maillons Rapides, were under 5 kg.
Risers length,
Measured wit-
hout carabiner.
Carabiners len-
ght : 29 mm.
Tolérance +/- 5mm
A B C D Frein
Manual Tested
sample
Diff Manual Tested
sample
Diff Manual Tested
sample
Diff Manual Tested
sample
Diff Manual Tested
sample
Diff
Center
1 7451 7460 9 7349 7353 4 7521 7521 0 7586 7584 -2 8461 8459 -2
2 7357 7363 6 7255 7259 4 7421 7415 -6 7485 7477 -8 8193 8192 -1
3 7398 7403 5 7295 7298 3 7454 7453 -1 7512 7507 -5 7975 7982 7
4 7345 7348 3 7247 7250 3 7382 7382 0 7436 7432 -4 7868 7865 -3
5 7216 7217 1 7123 7124 1 7249 7246 -3 7299 7294 -5 7667 7665 -2
6 7219 7219 0 7130 7129 -1 7242 7241 -1 7286 7284 -2 7506 7505 -1
7 7054 7062 8 7003 6998 -5 7081 7078 -3 7438 7434 -4
8 6897 6892 -5 6865 6860 -5 6935 6929 -6 7479 7474 -5
9 6826 6827 1 6823 6820 -3 6887 6887 0 7322 7314 -8
10 7264 7256 -8
Stabilizers
11 6538 6530 -8 6513 6506 -7 6566 6559 -7 7238 7232 -6
Wingtip
12 6419 6410 -9 6438 6432 -6 6501 6492 -9
RISERS Non accéléré Accéléré
Manual Tested
sample
Diff Manual Tested
sample
Diff
A
517 516 -1 357 359 2
A'
517 516 -1 361 359 -2
B
517 518 1 410 411 1
C
517 518 1 517 518 1
RISERS Non accéléré Accéléré
Manual Tested
sample
Diff Manual Tested
sample
Diff
A
545 544 -1 385 387 2
A'
545 544 -1 385 387 -2
B
545 546 1 438 439 1
C
545 546 1 545 546 1
Risers length,
Measured with
carabiner.
Tolérance +/- 5mm
