SUPAIR Step - Lines Individual Lengths (Page 28)

Glider user's manual | STEP
SUPAIR | STEP | page 28
Maintenance sheet
STEP size L
Lines individual lenghts
A LINES B LINES C LINES D LINES BRAKE LINES
NAME CUT SEWN NAME CUT SEWN NAME CUT SEWN NAME CUT SEWN NAME CUT SEWN
AR1 5002 4752 BR1 4939 4689 CR1 5075 4825 d1 797 597 BRML 1751 1551
AR2 5278 5028 BR2 5208 4958 CR2 5315 5065 d2 780 580 BRmain 1492 1492
AR3 5413 5163 BR3 5392 5142 CR3 5478 5228 d3 780 580 BRM1 2292 2092
a1 2911 2711 b1 2874 2674 CM1 2390 2190 d4 716 516 BRM2 2727 2527
a2 2817 2617 b2 2780 2580 CM2 2306 2106 d5 687 487 BRM3 3316 3116
a3 2858 2658 b3 2820 2620 CM3 2333 2133 d6 677 477 BRMU1 2158 1958
a4 2522 2322 b4 2495 2295 CM4 2076 1876 BRMU2 1856 1656
a5 2393 2193 b5 2371 2171 CM5 1968 1768 BRMU3 1294 1094
a6 2396 2196 b6 2378 2178 CM6 1965 1765 BRMU4 1330 1130
a7 2098 1898 b7 2067 1867 c1 734 534
STABILO LINES
br1 1765 1565
a8 1941 1741 b8 1929 1729 c2 718 518
NAME CUT SEWN
br2 1497 1297
a9 1865 1665 b9 1882 1682 c3 724 524 STMain 5414 5214 br3 1581 1381
a10 662 462 b10 637 437 c4 664 464 STRis 505 305 br4 1474 1274
c5 639 439 STMA 769 569 br5 1400 1200
c6 635 435 STMB 790 590 br6 1239 1039
c7 2055 1855 sta 541 341 br7 1135 935
c8 1909 1709 stb 539 339 br8 1176 976
c9 1861 1661 stc 602 402 br9 1557 1357
c10 669 469 br10 1499 1299
br11 1473 1273
