BATTERY CARE & MAINTENANCE
Important notes to help prolong the life of the battery:
• Before the first use of your battery, put it on charge for 24 hours.
• Do not place the battery on a concrete floor for charging, have
the battery raised off the floor on wooden blocks or place the
battery on a shelf.
• To fully charge the battery, choose a place where ambient
temperature is above 10 degrees Celsius.
• Always recharge your battery as soon as possible after use.
• When yellow light is “On” you should recharge your battery as
soon as possible.
• Never use the battery when the red light is “On”. You will
discharge the battery below its designated voltage and damage
it.
• Do not drop the battery.
• STORAGE:
If you know that you will not be using your battery in the near
future, disconnect the battery from the charger and store it in a
suitable dry place.
Recharge your battery before you use it or every 3 months (No
more than 3 months) if it is not used in that period.
• Always contact our service agent before you replace the battery
or the charger. Using an incompatible battery or charger may
damage the scooter and void your warranty.
- 35 -
Specifications
Number of Wheels 4
Front Wheel Size 200mm (8”)
Rear Wheel Size 200mm (8”)
Ground Clearance (tiller)
60mm (2.4”)
Length 1010mm (40”)
Width 570mm (22.5”)
Weight Without Seat
Front frame : 10.2kg (22.4 lbs)
Front Frame Without Front wheels
:8.5kg (18.7 lbs)
Rear Frame : 10kg (22 lbs)
Weight of Seat 7.7kg (17 lbs included seat frame & armrest)
Max Loading 125kg (275 lbs) on level ground
Turn Radius 910mm (36”)
Motor Output 2 - 150 Watt
Transmission Worm Drive Gearbox
Reverse Forward/Reverse Switch
Brakes Dynamic Braking and Electromagnetic Brake
Battery (SLA/Lithium)
6.5 kph (4 mph)
2
nd
speed choice 3.9 kph (2.4 mph)
Slope Grade Ability
9 Degrees with120kg (260 lbs) load.
12 Degrees with 100kg (220 lbs) load
Travel Distance
Up to 16km (10 miles) with standard SLA battery, or
20Km (12.4 miles) with 24V 15ah lithium battery.
Arm Rests
Distance between armrests 45cm - 55cm (18 -22")
- 36 -
