Super Ego SEGO RECV R32 - User Manual

Super Ego SEGO RECV R32
56 pages
Go to English
Print Icon
To Next Page IconTo Next Page
To Next Page IconTo Next Page
Loading...
E Unidad de recuperación
GB Recovery unit
F Unité de récupération
P Recuperador
I Unità di recupero
PL Urządzenie do odzysku czynnika
SEGO RECV R32

Questions and Answers

  • M
    matthewjacksonAug 9, 2025
    What to do if pressing the 'O' button on my Super Ego SEGO RECV R32 Test Equipment doesn't start the compressor?
    • S
      Suzanne BarronAug 10, 2025
      If pressing the 'O' button on your Super Ego Test Equipment fails to start the compressor, it could be due to the following reasons: * High pressure protection shut off, indicated by a red alarm light. Lower the pressure of the unit. * Low pressure protection is active, indicated by a green alarm light, which usually means recovery isn't finished. Check if the hoses are well connected. * The 80% O.F.P. cable might not be properly connected. Check the connection. * If the “O” light is not bright, there may be an internal wiring fault. Have it checked by a qualified technician or seek factory service.
  • T
    twangAug 14, 2025
    How to fix a jammed compressor on Super Ego SEGO RECV R32?
    • N
      Nancy JimenezAug 15, 2025
      If the compressor on your Super Ego Test Equipment is jammed, it could be due to: * External pressure being too high. When recovering liquid, turn the knob to the “START” position, then restart. When recovering vapor, turn the knob to “PURGE”/”3” position, then restart. * Motor failure or other components being damaged. You can replace the components, or factory service may be needed.
  • G
    gchristensenAug 19, 2025
    Why is the recovery speed slow on my Super Ego SEGO RECV R32?
    • B
      Brandy ScottAug 19, 2025
      A slow recovery speed on your Super Ego Test Equipment can be caused by: * The pressure of the refrigerant tank being too high. Cooling the tank down can help reduce the pressure. * A damaged piston ring in the compressor. You can replace the components, or factory service may be required.
  • N
    Nicholas MitchellAug 25, 2025
    What to do if my Super Ego SEGO RECV R32 Test Equipment unit doesn’t pull out a vacuum?
    • C
      charles39Aug 25, 2025
      If your Super Ego Test Equipment unit isn’t pulling a vacuum, consider these potential causes: * Loose connecting hoses. Tighten the hose connections. * Leakage in the unit. You can replace the components, or factory service may be required.
  • K
    Kimberly RubioAug 29, 2025
    How to troubleshoot a fan with no response in Super Ego SEGO RECV R32?
    • T
      Timothy LeeAug 29, 2025
      If the fan in your Super Ego Test Equipment is not responding, it is likely due to mechanical damage. Replace the fan, or factory service may be required.
  • L
    Lisa ReyesNov 3, 2025
    Why does my Super Ego Test Equipment compressor start and then stop after a few minutes?
    • E
      Elizabeth ShannonNov 3, 2025
      There are several reasons why your Super Ego Test Equipment compressor might start and stop within a few minutes: * High pressure shut off due to incorrect operation, such as the outlet valve or refrigerant tank valve not being open. Refer to the Operation Manual for proper procedures. * The motor thermal protector shuts off. The compressor will restart automatically after a few minutes. * The circuit breaker shuts off. Cool the circuit breaker down and press it to restart after 5 minutes. * 80% over filling protection is activated, indicated by a red alarm light. Replace with an empty recovery tank. * Recovery is over. Refer to the self-purge method. * Under low pressure protection, indicated by a green alarm light. Turn the knob to the ‘START’ position, then restart. * Ove...

Summary

Introduction

Equipment Overview

Important Use Information

General Operation Manual

Technical Data and Specifications

Refrigerant Pipes Exhaust

Connection Diagram

Diagram illustrating pipe connections for refrigerant exhaust.

Preparation for Operation

Steps required to prepare the unit and pipes before refrigerant exhaust.

Starting the Operation

Instructions for initiating the refrigerant exhaust process.

Finishing the Operation

Steps to conclude the refrigerant exhaust operation.

Refrigerant Recovery Mode

Connection Diagram

Diagram showing unit connections for refrigerant recovery.

Preparation for Operation

Steps to prepare the unit for refrigerant recovery.

Starting the Operation

Instructions for starting the refrigerant recovery process.

Self-Purge Mode

Connection Diagram

Diagram illustrating unit connections for self-purge.

Preparation for Operation

Steps to prepare the unit for self-purge.

Finishing the Operation

Steps to conclude the self-purge operation.

Liquid Push;Pull Mode

Connection Diagram

Diagram for connecting the unit in liquid push/pull mode.

Preparation for Operation

Steps to prepare for liquid push/pull mode operation.

Starting the Operation

Instructions to start the liquid push/pull recovery.

Finishing the Operation

Steps to conclude the liquid push/pull operation.

Troubleshooting

Super Ego SEGO RECV R32 Specifications
