8. Extension Cords
Do not use reeled or coiled cable. Reeled or coiled cable can produce a counter EMF (electromotive force). The counter EMF can
reduce the current carrying capability of an extension cord. This counter EMF will result in a voltage drop within the motor
instigating a thermal overload condition. Power supply must handle wattage requirements. When conditions require the use of
reeled cable, unreel all cable and place on the ground in very loose overlapping non-uniform coils.
Units
1
WATTS
2
Minimum Wire Gauge Maximum Cable Length (feet)
1
2000 14 150
2
4000 12 250
3
6000 10 350
1
Multiple units powered by one extension cord.
2
Minimum running wattage for multiple units. Startup amperage draw is much higher.
9. Extension Ducts
Spiral duct may be used on the intake or exhaust side of a ventilator.
Exhaust Side
1
Maximum 40 feet
Intake Side
1
Maximum 20 feet
“L” Duct
1
Exhaust side only
1
Adapter required, optional, not included with ventilator.
