V18-BL PPV User Guide
Revised 9-2019
POSITIVE PRESSURE VENTILATOR
ITEM PART NUMBER QTY DESCRIPTION
1
FRAME, V18-BL 1 FRAME, WLDMNT V18-BL
2 V18-
BL_Power_Supply_
Box 1 BOX, POWER SUPPLY, V18-BL (OPTIONAL)
3
033-10874 10 NUTSERT, TSN RIBBED, 10-24 (OPTIONAL)
4
005-15355 1 POWER SUPPLY, 750W, 24V, V18-BL
5
019-20268 1 COVER, POWER SUPPLY, V18-BD (OPTIONAL)
6
032-10096 3 SCREW,SHCS,SHCS M4x0.7x6
7
065-12852 3 STRAIN RELIEF,DOMED,SCR .24-.47,1/2 NPT,BLACK
8
065-12856 2 LOCKNUT,NYLON,1/2 NPT,BLACK
9
032-10757 4 SCREW,PHP,10-24 UNCx0.75
10
024-13473 4 FEET RUBBER CONE SHAPE VBM-4002
11
012-14196 2 INSERT, 3/8-16, TUBE, V-BD AXLE MOUNT
12
019-20253 1 TUBE, WHEEL SUPPORT, V18-BD
13
008-13804 2 WHEEL, V18-BD, 6 INCH
14
032-14564 2 SCREW,BHSH,3/8-16x2-1/2,SS
15
005-10256 10 PLUG, 1.25, TUBE END ROUND, VALOR
16
019-20266 1 COVER, CONTROLLER BOX, V18-BD
17
021-10514 1 CONTROLLER, HOAG, 18V / 36V DC MOTOR
18
065-00920 1 SHORE PLUG, V18-BD
19
032-10101 4 SCREW,PHP,8-32 UNCx0.5
20
034-10963 14 SCREW,PHP,10-24 UNCx0.5
21
005-10269 1 BUSHING, ROTATION, V18-BD
22
005-10271 2 GROMMET,PUSH-IN,0.75 ID,1.125 OD,0.0938 GROOVE
23
005-13563 1 LIGHT, LED, V18-BD
24
005-10270 1 WASHER, RUBBER, ROTATION, V18-BD
25
019-20276 1 SHROUD, V18-BD
26
012-15393 1 STREAMSHAPER GUARD FOR 18" PPV FAN
27
025-16020 1 DECAL, SHROUD, CENTER, V18,V16-BD
28
008-10193 1 KEYSTOCK,SHAFT,BLADE,718, V-18
29
003-15320 1 BUSHING,BLADE, V18-BD
30
032-10743 2 SCREW,HH,1/4-20x3/4,SS
31
021-10523
1
MOTOR,1 HP TEAO,48VDC, V18-BD
32
032-10119
4
SCREW,HH,M5x0.8x12,SS
33
021-10524
1
COVER, MOTOR, V18-BD
34
032-10118
1
SCREW,PPH,M3 X 0.5 x 8 mm
35
034-11073
1
NUT,NYLOCK, 3/8-16 UNC,SS
36
005-10266
1
HANDLE, TENSION, V18-BD
37
HANDLE, V18-BL
1
HANDLE, V18-BL, WLDMNT
38 Milwaukee_Battery_
Mount_Spacer
3
MILWAUKEE_BATTERY_MOUNT_SPACER
39 Milwaukee_Battery_
Mount_Lower
4
MILWAUKEE_BATTERY_MOUNT_LOWER
40
005-16103
8
ADAPTER, MILWAUKEE, ODM, V18-BL
41
032-10121
8
SCREW,FHPMS,4-40 UNC x 5/16 in,SS
42
032-10122
4
SCREW,FHPMS,4-40 UNC x 3/4 in,SS
43
4-40_Nut_Steel
2
44
4-40_Nut_Plastic
2
45
032-10110
4
SCREW,FHPMS,5/16-18 UNC x 7/8 in,SS
46
032-10789
4
NUT,NYLOCK, 5/16-18 UNC,SS
47
005-10255
4
T-HANDLE, PLUNGER, VALOR
48
032-10123
6
NUT, 4-40, ZINC
49
032-10695
2
NUT,MS,HEX2,8-32UNC,SS
50 STD HARDWARE-
FHMS-66
4
SCREW,FHPMS,8-32 UNC x 3/4 in,SS
51
065-00923
2
POTENTIOMETER, V18-BD
52
005-10267
2
KNOB, POTENTIOMETER, V18-BD
53 V18-
BL_Wiring_Plate
8
WIRING COVER PLATE, V18-BL
54
032-10754
8
WASHER,LOCK,SPRING,REGULAR, 1/4", SS
55
STD HARDWARE-28
22
WASHER,LOCK,SPRING,REGULAR, #10, SS
56
005-16100
1
BATTERY, MILWAUKEE, 12AH, V18-BL
57
005-13562
1
SWITCH, MOMENTARY, RGB, V18-BD
58
005-13564
1
SWITCH, LATCHING, V18-BD
59
025-16018
1
DECAL, SHROUD, CHEVRON, V18-BD
60
025-16016
2
DECAL, TOP, V18-BD
61
025-16017
4
DECAL, SERIAL NUMBER, V18-BD
62
025-16019
3
DECAL, SIDE, V18, V16-BD
63
003-15320
2
BLADE, PLASTIC, 30DEG, V18-BD (ALUMINUM BLADE AVAILABLE)
10. Parts List
