Super 3600 - Programming Operations; Setting Microswitches for Super 3600; Programming Total Opening; Programming Pedestrian Gateway Opening

3. Set the microswitches for SUPER 3600 DIP 1-2-3-4-5-6-7-8-9-10-11-14-15-16 on OFF and DIP 12-13 ON ON.
4. PROGRAMMING TOTAL OPENING.
NOTE: If the STOP, PHOT 1, PHOT 2, EDGE 1 and EDGE 2 inputs are not connected, make jumpers between COM A + / STOP / PHOT 1 / PHOT 2 / EDGE 1 / EDGE 2 before proceeding with programming.
NB: In this case the Edge, Photocell and Stop button safety devices will be ignored. The LEDs DL6-7-8-9-10 must be on.
1 - IMPORTANT: POSITION THE GATE AT APPROXIMATELY 20 CM FROM THE CLOSING LIMIT SWITCH.
2 - Put the DIP 2 in the ON position => the DL1 LED begins to flash.
3 - Press the PROG./RADIO/OPEN/START button. The gate will begin a series of movements. DO NOT WALK IN FRONT OF THE PHOTOCELLS WHEN THE GATE IS MOVING. Set up is complete when
the gate remains closed and the DL1 LED is o.
4 - Turn the DIP 2 back to the OFF position.
5. PROGRAMMING THE PEDESTRIAN GATEWAY OPENING
With the gate closed:
1 - First set DIP2 to ON (DL1 led flashes quickly) and after DIP1 to ON (DL1 led flashes slowly).
2 - Press the pedestrian button (COM A+/PED.) => M1 opens.
3 - Press the pedestrian button (COM A+/PED.) To stop M1 at the desired point.
4 - Press the pedestrian button (COM A+/PED.) To close M1.
5 - When the closure is reached, reset DIP 1 and 2 to OFF.
6. PROGRAMMING THE REMOTE CONTROL FOR TOTAL OPENING
Programming can be done only when the gate is stationary.
1 - First set DIP 1 to ON and then DIP 2 to ON. The LED DL12 flashes red for 10 seconds.
2 - Press the remote button (usually channel A) within the allotted 10 seconds. If the remote is memorized properly LED DL12 blinks green and a buzzer tone confirms the correct memorization.
The 10 seconds for programming the codes are automatically renewed, with LED DL12 which flashes red, in order to store the next transmitter.
3 - To finish programming, wait 10 seconds, or press the PROG button briefly. LED DL12 stops flashing.
4 - Re-set DIP 1 to OFF and DIP 2 to OFF.
7. Customising configuration
You can change the configuration by moving the various micro-switches
DIP 4 Photocells always active (OFF) - Photocells active only during closing (ON)
DIP 5 Pre-blinking (ON) - Normal blinking (OFF)
DIP 6 Single pulse command (START) and RADIO - step-by-step (ON) - automatic (OFF)
DIP 7 Photocells AUTO-TEST activation (ON-activated).
DIP 8 Encoder management (not available)
DIP 9 Slowdown (not available)
DIP 10 Electronic brake (not available)
DIP 11 Gradual start (not available)
DIP 12 Activate the radio system SUN/MOON (ON) - SUN-PRO (OFF)
DIP 13 SUPER 3600 (ON).
IMPORTANT: The system must comply with all the standards and Directives currently in force.
ATTENTION: Install the APP card (or the APP+ card with its modules) and use your smartphone with the RIB GATE App to take advantage of all the advanced features that the L1 control
board can oer you.
