Super SD - Consolidated Parts List

•
SD / LD / SL / HD / HL / SN
Parts list
16A 16B 17 17A 17A-1 18 19 19A 20 20-1 21
循環接頭
Recycle
Joint
PVDF
塞頭
Plug
FRPP
自吸筒
Self-Priming
Cover
FRPP /
CFRPP
CPVC /PVDF
自吸筒螺絲
Self-Priming
Cover Screw
PVDF / SUS
自吸筒螺絲
O
環
Cover Screw
O-ring
NBR / EPT
/ VITON
自吸筒墊片
Self-Priming
Cover Packing
NBR / EPT
/ VITON
TEFLON
SL
底座
Base for SL
FC
SD/SE
腳架
Base
for SD/SL
FRPP
連軸器
Coupling
FC
連軸器橡膠
Coupling
Elastomer
NBR
連軸器護罩
Coupling
Shield
SUS
11 12 12-1 13 14 15 15-1 16 16-1 16-2
葉輪
Impeller
FRPP /
CFRPP
CPVC / PVDF
葉輪螺絲
Impeller
Screw
FRPP /
CFRPP
CPVC /PVDF
葉輪螺絲
O
環
Impeller Screw
O-ring
NBR / EPT
/ VITON
中封蓋
Check Cover
FRPP /
CFRPP
CPVC / PVDF
單向閥
Check Valve
NBR / EPT
/ VITON
TEFLON
注水蓋
Water Filling
Cap
FRPP /
CFRPP
CPVC / PVDF
注水蓋
O
環
Water Filling
Cap O-ring
NBR / EPT
/ VITON
循環管
含接頭
Recycle
Hose
TEFLON
循環接頭墊片
Recycle Joint
Packing
NBR / EPT
/ VITON
鐵氟龍管
Teon Hose
TEFLON
9 9-1 9-2 9-3 9-4 9-5 9-6 10 10-1 10-2
前軸封
Bellows-seal
combination
轉動環
Rotational
-seal
CARBON
/ SSIC
伸縮環
Bellows
TEFLON
彈簧
Bellows Spring
HASTELLOY-C
/ SUS316
伸縮環前
O
環
Bellows Front
O-ring
NBR / EPT
/ VITON
伸縮環墊片
Bellows
Packing
NBR / EPT
/ VITON
TEFLON
伸縮環後
O
環
Bellows Rear
O-ring
NBR / EPT
/ VITON
固定環
Fixed-seal
CERAMIC /
SSIC
固定環後
O
環
Fixed-Seal
Rear O-ring
NBR / EPT
/ VITON
固定環
O
環
Fixed-Seal
O-ring
NBR / EPT
/ VITON
1 2 2A 2B 2C 3A 3B 4
馬達
Motor
FC
腳座
Frame
FC FRPP FC
3.75kW
腳座軸承
Frame Bearing
STEEL
軸承防塵蓋
Bearing
Dust Shield
FC
軸承防水套
Bearing
Liquid Shield
PP
後封蓋
Rear cover
FRPP /
CFRPP
CPVC / PVDF
LD
型一體成型
後封蓋
Combined
Rear cover
FRPP
後蓋
O
環
Rear Cover
O-ring
NBR / EPT
/ VITON
5A 5B 5C 5D 6 7 7-1 8 8-1
軸套
Shaft Sleeve
TEFLON
軸心
Shaft
SUS
軸心固定
螺絲
Shaft Screw
SUS
葉輪鍵
Impeller Pin
SUS
主體前蓋
Front Cover
FRPP / CFRPP
CPVC / PVDF
軸封護罩
Seal Cover
FRPP /
CFRPP
CPVC / PVDF
軸封護罩
O
環
Seal Cover O-ring
NBR / EPT
/ VITON
固定環座
Fixed-seal Socket
PPS / FRPP /
CFRPP
CPVC / PVDF
固定環座
O
環
Fixed-seal socket
O-ring
NBR / EPT
/ VITON
(
每台
2
條
)
SL
SD/LD
SD/LD
1-1/2”-2” 3”
(有舌) (無舌)
SL
SD
22
