SuperFish TopClear Filter 5000 - TopClear Filter Specifications

2
B
max 2m
>5cm
>5cm
min 0.5m
E
OUT
D
IN
b
c
e
a
d
d
CLEAN
Optional
BackWash Valve
CLEAN
A C
SuperFish TopClear Filter 5000 - 10000 - 15000 - 18000
Technical specications
TopClear Filter 5000 (Kit) 10000 (Kit) 15000 18000 Kit
Max. pond content 5,000 l 10,000 l 15,000 l 18,000 l
Max. pump capacity 2,500 l/h 3,500 l/h 5,000 l/h 5,500 l/h
UVC 7 watt 9 watt 11 watt 18 watt
Voltage 220-240 V/50 Hz 220-240 V/50 Hz 220-240 V/50 Hz 220-240 V/50 Hz
Filter inlet 14/20/25 mm 25/32/40 mm 25/32/40 mm 25/32/40 mm
Filter outlet 14/20/25 mm 25/32/40 mm 25/32/40 mm 25/32/40 mm
Dimensions 34x34x40 cm 35x44x46 cm 35x44x58 cm 35x44x58 cm
Capacity of the pump* 2,000 l/h 2,900 l/h N/A 5,300 l/h
Pump* 25 watt 45 watt N/A 29 watt
Replacement UV lamp Art. 06011010 Art. 06011015 Art. 06011020 Art. 06011040
Replacement Quartz kit Art. 06010350 Art. 06010350 Art. 06010355 Art. 06010355
* Applicable only to the TopClear 5000 Kit, TopClear 10000 Kit and TopClear 18000 Kit
