Superior IO-360 SERIES User Manual

Installation & Operation Manual
O-360 and IO-360 Series Engines
© March 2004 Superior Air Parts Inc. Chapter 1 • Engine Description
4
Table 1-2 • Manufacturer’s Physical Specifications
Model
Height
(In)
Width
(In)
Length
(In)
Weight
O-360 24.6 33.4 32.8 See MSD
IO-360 24.0 33.4 32.8 See MSD
Table 1-3 • Views of the Engine
Engine View Figure Number Location
O-360 Engine Front View Figure 1-2 p. 5
O-360 Engine Left Side View Figure 1-3 p. 6
O-360 Engine Top View Figure 1-4 p. 7
O-360 Engine Rear View Figure 1-5 p. 8
IO-360 Engine Front View Figure 1-6 p. 9
IO-360 Engine Left Side View Figure 1-7 p. 10
IO-360 Engine Top View Figure 1-8 p. 11
IO-360 Engine Rear View Figure 1-9 p. 12

Superior IO-360 SERIES Specifications

General

Brand	Superior
Model	IO-360 SERIES
Category	Engine
Language	English
