Installation & Operation Manual

O-360 and IO-360 Series Engines

List Of Figures

Figure

Number

Figure Description Chapter Page

1-1 Model Number Designation 1 1

1-2 O-360 Engine Front View 1 5

1-3 O-360 Engine Left Side View 1 6

1-4 O-360 Engine Top View 1 7

1-5 O-360 Engine Rear View 1 8

1-6 IO-360 Engine Front View 1 9

1-7 IO-360 Engine Left Side View 1 10

1-8 IO-360 Engine Top View 1 11

1-9 IO-360 Engine Rear View 1 12

3-1 Oil System Schematic 3 14

3-2 Ignition Wiring Diagram 3 17

3-3 Alternator Mounting Pad 3 21

3-4 #1 Dynafocal Mount Dimensions 3 23

3-5 #2 Dynafocal Mount Dimensions 3 23

3-6 Conical Mount Dimensions 3 24

3-7 Limit and Ultimate Engine Forces 3 26

3-8 Engine Mount Forcing Function for Engine Startup and Shutdown 3 27

3-9 Engine Mount Forcing Function for Steady State Conditions 3 27
