Superior IO-360 SERIES User Manual

Installation & Operation Manual
O-360 and IO-360 Series Engines
© March 2004 Superior Air Parts Inc. Chapter 1 • Engine Description
12
TACHOMETER CONNECTION
VACCUM PUMP / ACCESSORY PAD
OIL PRESSURE GAGE CONNECTION
OIL LEVEL TUBE & GAGE
MANIFOLD
PRESSURE
CONNECTION
GROUND OR “P-LEAD” TERMINAL
OIL SUPPLY TO COOLER
OIL LINE TO
PROPELLER
FUEL PUMP INLET
OIL DRAIN PLUG
OIL SUCTION
SCREEN
THROTTLE CONTROL
LEVER
OIL DRAIN PLUG
VENT LINE CONNECTION
DIAPHRAGM FUEL
PUMP
GROUND OR “P-LEAD” TERMINAL
OIL FILTER
OIL RETURN FROM COOLER
FUEL INJECTION MANIFOLD
BREATHER FITTING
ALTERNATE OIL
TO COOLER
OIL TEMP
CONNECTION
EYE
BRACKET
MIXTURE CONTROL
LEVER
Figure 1- 9 • IO-360 Engine Rear View
