Superior IO-360 SERIES User Manual

Model Specification Data
O-360 Series Engine
14 Appendix A • O-360 Model
© March 2004 Superior Air Parts Inc. Specification Data
Figure 13 • Fuel Mixture Curve-65% Power
Economy Cruise Fuel Mixture Curves
Superior Vantage O-360 Series
24 in-Hg x 2400 RPM
-250
-200
-150
-100
-50
0
46.9 48.9 50.9 52.9 54.9 56.9 58.9 60.9 62.9 64.9 66.9 68.9 70.9 72.9 74.9
Below Peak EGT (°F)
-75
-50
-25
0
46.0 48.0 50.0 52.0 54.0 56.0 58.0 60.0 62.0 64.0 66.0 68.0 70.0 72.0 74.0 76.0
Below Peak CHT (°F)
80
90
100
110
120
46.0 48.0 50.0 52.0 54.0 56.0 58.0 60.0 62.0 64.0 66.0 68.0 70.0 72.0 74.0 76.0
Corrected Power (Hp)
0.40
0.45
0.50
0.55
0.60
0.65
0.70
46 48 50 52 54 56 58 60 62 64 66 68 70 72 74 76
BSFC (Lb/Hp-hr)
Fuel Flow (Lbs/hr)
