Superior IO-360 SERIES User Manual

Model Specification Data
O-360 Series Engine
16 Appendix A • O-360 Model
© March 2004 Superior Air Parts Inc. Specification Data
Notes: (1) Typical Heat Rejection In Cruise
(2) Maximum Heat Rejection at Full Power and Limiting Oil Temperature
Table 1 • Maximum Fuel Flow Requirements
Max Rich Fuel Flow Required (Pounds Per Hour)
O-360 108
Table 3 • Fuel Pump Inlet Pressure Limits
Minimum (PSIG) Maximum (PSIG)
O-360 +0.5 +8
Table 4 • Oil Heat Rejection, Airside Heat Rejection, Crankcase Pressure
Typical (1) 450 BTU/Minute
Oil Heat Rejection
Maximum (2) 1000 BTU/Minute
Minimum
1800 Ft
3
/Min (Sea Level)
(6.3 In-H
2
O Baffle Press Drop)
Cylinder Cooling Airflow
Recommended
2200 Ft
3
/Min (Sea Level)
(6.5 In-H
2
O Baffle Press Drop)
Crankcase Pressure
Maximum 4.0 In-H
2
O
Table 2 • Fuel Filter Requirements
100 Mesh Screen 0.005 Max Particle Size
