PARTS
This list contains replaceable parts used in your firebox. When ordering parts, follow the instructions listed under Replacement Parts on
page 15 of this manual.
KEY
NO. CATALOG NO. DESCRIPTION
VRE6036
F4225
VRE6042
F4226
VRE6050
F4227 QTY.
1 ** FACE ASSEMBLY • • • 1
2 ** FIREBOX BOTTOM ASSEMBLY • • • 1
3 ** FIREBOX BOTTOM • • • 1
4 ** FIREBOX SURROUND • • • 1
5 ** INSULATION PAN SUPPORT • • • 1
6 ** INSULATION PAN • • • 1
7 ** TOP INSULATION • • • 1
8 RP110454-03 TOP, FIREPLACE 36" • 1
RP110454-02 TOP, FIREPLACE 42" • 1
RP110454-01 TOP, FIREPLACE 50" • 1
9 J6997 SPACER, FIREPLACE TOP 42MC • • • 4
10 ** FIREPLACE SURROUND ASSEMBLY • • • 1
11 J4362 SPACER, CLEARANCE 36/42/50" • • • 6
12 J5329 BRACKET, F/P HANDLE • • • 4
13 J6900 PLATE,OUTSDE AIR COVER 36E44-6 • • • 2
14 J6934 COVER, GAS CONDUIT PLATE 36E • • • 4
15 J4368 GAS, CONDUIT ONE • • • 2
16 J4369 GAS, CONDUIT TWO • • • 2
17 ** HEAT SHIELD SUPPORT • • • 1
18 ** FIREBOX TOP • • • 1
19 J5307 SCREEN,STAINLESS 29.312"HX 23" • 2
J5306 SCREEN,STAINLESS 29.312"HX 30" • 2
J5305 SCREEN,STAINLESS 29.312"HX 26" • 2
20 J5310 ROD, SCREEN FORMED S.S. JM36 • 2
J5309 ROD, SCREEN FORMED S.S. JM50 • 2
J5308 ROD, SCREEN FORMED S.S. JM42 • 2
21 J4353 HOOD, DEFLECTOR 50" S.S. • 1
J4354 HOOD, DEFLECTOR 42" S.S. • 1
J4355 HOOD, DEFLECTOR 36" S.S. • 1
PARTS AVAILABLE NOT SHOWN
J4357 SPACER, REFRACTORY 36 • • • 4
RP114913-01 REAR REFRACTORY SPACERS • • • 2
** Not a field replaceable part.
WARNING: Contact an IHP dealer to obtain any of these parts. Never use substitute materials not approved
by IHP. Use of non-approved parts can result in poor performance and safety hazards.
