Chapter 1: Introduction
1-7
System resource alert via Supero Doctor III•
ACPI Features
Slow blinking LED for suspend state indicator•
Main switch override mechanism•
ACPI Power Management•
Keyboard Wakeup from Soft-off •
Onboard I/O
Intel ICH10R supports six SATA2 ports (with RAID0, RAID1, RAID10, RAID5 •
supported in the Windows OS Environment) (Note 1)
LSI 1068E supports eight SAS ports (with RAID 5 optional) (For X8DT3/-F/-
•
LN4F) (Note 2)
Intel 82576EB dual-port Gigabit Ethernet controllers support Giga-bit LAN
•
ports (an additional 82576EB is available on the X8DT3/i-LN4F only)
One fl oppy port interface and two COM ports (1 header, 1 port)
•
One VGA Port supported by the WPCM450 BMC Controller•
PS/2 mouse and PS/2 keyboard ports•
Up to eight USB 2.0 (Universal Serial Bus) (2 Backpanel USB Ports, 2 Front •
USB Headers, and 2 Type A Headers)
Super I/O: Winbond W83627HG
•
IPMI 2.0 with full KVM support (X8DT3/i-F/-LN4F only) (Note 3)•
Other
Wake-on-LAN (WOL)•
Console redirection•
Onboard Fan Speed Control by Thermal Management via BIOS•
CD/Diskette Utilities
BIOS fl ash upgrade utility and device drivers•
Dimensions
Ext. ATX 12.00" (L) x 13.00" (W) (304.80 mm x 330.20 mm)•
Note 1: For more information on SATA HostRAID confi guration, please
refer to the Intel SATA HostRAID User's Guide posted on our website @
http://www.supermicro.com/support/manuals/.
Note 2: For more information on LSI SAS RAID confi guration, please refer
to the LSI MegaRAID User's Guide posted on our website @ http://www.
supermicro.com/support/manuals/.
Note 3: For more information on IPMI confi guration, please refer to the
Embedded IPMI User's Guide posted on our website @ http://www.super-
micro.com/support/manuals/.
