Required Material and Tools
1. 8×25kg sand bags
2. Adjustable wrench
3. Hammer
NOTE : Bolt kit check list is included in the bolt kit. Be sure to check contents
prior to assembly. (Two men required for assembly )
Insert the rod through wheels and bottom pole holes with base (P1).
Attach support tubes P7
at the both side of the
base (P1) using nut &
bolt A-45×8mm & use
two holes strip (H) as a
washer under the base
STEP-2
Attach both other side of tube (P7)
with lower pole using nut & bolt
(D-110×8mm) & tighten it with
the help of two spanners
STEP-3
4. 13mm Wrench/socket
5. Large screwdriver
6. 2 block wood approx. 10×10×3cm
Fill the base (P1) with water or sand
STEP-4
Warning
This unit can hold 120 Liters of water instead
of sand. In case of using water make sure that
base P1 is close properly with ring gasket inside
the cap. In case of using water strongly advice to
control the tightness of the base every time you
are going to play.
STEP-1
OR
STEP-1
Page-4
