Bring down the pole to insert U-bolt (E) with top pole and tighten
the nut with the help of spanner of the U-bolt attached with ring.
STEP-9
Page-6
Attach support strip (P5) with lower pole attached to (P1) using
nut & bolt (D) and tighten it with the help of spanner.
STEP-10
FOR ADDITIONAL STABILITY
STEP-11
Locate the unit at desired playing location.
Start the installation of the ground anchor
(J-125×8mm) by hand approximately 8cm
behind unit. Finish installing the anchor by
inserting large screw driver into the eye
of the anchor and twisting until only the eye is
remaining above ground.
Note : The anchor bolt should go through part (P5), (P1) .and steel strip (I)
To Next Page
