SUTO S 551 Series User Manual

5. Installation
To connect the different sensors please have a look to the designed
terminal.
Signal
Connector
1/2
Signal
Connector
M/M
Signal Colour
Connector
3/4
Connector
3/4
Dew point/
flow sensor
Modbus /
RTU
Pulse
active
Pulse
passive
SDI
N/A
+I /
Pulse brown
-V
-V
20 mA white
+V
+V
+V blue
N/A
+D
-V black
N/A
-D
+S grey
Signal Colour
Connector
3/4
Connector
3/4
Connector
3/4
Connector
3/4
Connector
3/4
Ampere
sensor
Pressure 1 V... 10 V 20 mA
active
20 mA
passive
+I /
Pulse brown
20 mA white
+V blue
-V black
+S grey
S 551 11
