Sutron Corporation 8310 & 7310 Users Manual 8800-1125Rev. 2.7 (BETA) 4/16/2014 pg. 132
With a Log Record, you can choose which pieces if information to log (measurement name,
units, quality, and value), change the order in which they appear, place a character between
measurements (such as the commas, shown above), and even place a character between the
name, quality, value, and units. This provides for easy formatting if using a spreadsheet or other
application where the separating character is important.
Using a Log Record is a two part process. First, the Log Record must be created- choose Add
Record in the Station Setup/Log Records menu, and define the necessary properties as
described below. Second, go to the menu of each measurement output (Station
Setup/Measurements/Mx/Mx.Ox) you want to include in the record, and update the RecordID
property to refer to the Log Record you just created. See the section Station Setup/Mx/Mx.Ox
earlier in this chapter for more information.
The Log Records menu appears like this:
Logs Records (1)
Record01 ►
Add record
Delete record
End Log Records
Add Record
When adding a log record, the system prompts for RecordID, Interval, and Time. See the
following section for descriptions of these properties.
Delete Record
This function deletes a log record. The system prompts for the record to delete, and prompts
make sure you want to actually delete the record. Once the record has been deleted, no more
records of the selected type will be logged.
Station Setup/Log Records/Log Record Details
Selecting a log record under the Station Setup/Log Records menu and pressing RIGHT brings up
a menu showing the properties of the highlighted log record, as shown below.
Record01
RecordID Record01
LogFile \Flash Disk\data.log
Interval 00:15:00
Time 00:00:00
Separator ,
HangingSeparator No
Fields (5) ►
End Record01
RecordID
The RecordID property defines the name of the record. Records are logged using this name.
