Sutron Corporation 8310 & 7310 Users Manual 8800-1125Rev. 2.7 (BETA) 4/16/2014 pg. 137
Basic Status: RUN
This item gives the status of the BASIC programs in the system. The status can be
STOP – no programs to run
Clear Cal Data
Cal data are slopes and offsets calculated during the calibration process that are applied to
inputs. The calibration data is kept with each measurement input. This function clears the cal
data by setting all the calslope to 1.0 and all the caloffset to 0.0.
See additional information in CalSlope/CalOffset.
Debug to System Log
This function instructs the software to produce additional debug information and write it to the
system log. Debug information is useful to help troubleshoot incorrect setups.
Select mux channel
This function allows you to manually select channels on a mux, typically for the purpose of
making manual measurements.
After pressing SET with this item highlighted, the system prompts you for the mux name, and
the initial channel to select, and then clocks-in the selected channel. Once the channel is
clocked-in, the system displays a message telling you the channel has been selected and its
associated measurement. If the channel is used by more than one measurement, the first will be
shown. If the channel is not in use, then no additional information will be displayed.
You may press any key to select the next channel, or when finished press Cancel.
NOTE: while a mux is manually selected, the system will not make scheduled measurements
that require that mux, so be sure to exit this menu as soon as you are done taking
measurements.
Upgrade Firmware
This function initiates the firmware upgrade process. Pressing SET will cause the system to look
for upgrade files on the local Flash Disk and SD Card (if one is inserted). If an upgrade is found,
the system will prompt whether to proceed with the upgrade. If more than one upgrade is
found and you press Cancel to the first prompt, the system will prompt regarding the next
upgrade found.
For more information regarding firmware upgrades generally, see Upgrading the Firmware in
Chapter 12.
Exit 8310 application
This function exits/stops the 8310 application. This should only be done when directed to do so
by Sutron Customer Service, typically as part of troubleshooting an issue. Exiting the
application will cause the system to no longer measure, log, and/or transmit data. To restart the
application you must access the 8310 command line (a “Flash Disk>” prompt), and type
/Windows/8310.exe.
