Sutron Corporation 8310 & 7310 Users Manual 8800-1125Rev. 2.7 (BETA) 4/16/2014 pg. 136
Exit 8310 application
End Diagnostics
Communications (n)
The number in parenthesis is the number of communications port that are configured to
operate. The /diagnostics/communications menu displays the state of each communications
port and provides a way to run tests on each port and display additional status.
See additional information in Diagnostics/Communications.
Inputs (n)
The number in parenthesis is the number of inputs configured in measurements. The
diagnostics/inputs menu allows you to view the last measured value for each input along with
the input number and I/O connection information. For many inputs, you can force a live
measurement by pressing SET/ENTER and Calibrate and view the Raw value by pressing RIGHT.
See additional information in Diagnostics/Inputs.
Outputs (n)
The number in parenthesis is the number of outputs configured in measurements. The
diagnostics/outputs menu allows you to view the last measured value for each output. For
some outputs, you can force a live measurement by pressing SET/ENTER and view data in the
log by pressing RIGHT.
See additional information in Diagnostics/Outputs.
I/O Modules (3)
The number in parenthesis is the number of I/O modules installed in the 8310. Each 8310 has
at least 3 I/O modules: the display, the analog I/O providing the analog inputs and the digital I/O
providing the digital inputs. The I/O Modules menu displays the name for each of the I/O
modules and provides details when needed.
See additional information in Diagnostics/I/O Modules.
SDI Tools
This menu provides tools useful in operating and maintaining SDI-12 devices. SDI-12 is an
industry standard protocol for serial smart sensors. The tools menu provides functions to find
devices that have been connected to the SDI-12 bus and communicate with them.
See additional information in Diagnostics/SDI Tools
System Status
System Status provides a way to view the following types of status: Recent Logged Messages,
SW version, communications, basic, I2C, serial number, num resets, and CPLD version.
See additional information in Diagnostics/System Status.
