Sutron Corporation 8310 & 7310 Users Manual 8800-1125Rev. 2.7 (BETA) 4/16/2014 pg. 141
Next pwr-off
Time of the next power off
Total bytes tx
Total number of bytes transmitted so far
Total bytes rx
Total number of bytes received so far
Total tx/rx errors
Total number of errors that have occurred while
transmitting or receiving. These are the kinds of errors that
would occur due to having poor view of the sky for the
antenna
Signal quality (0-5)
A number ranging from 0 to 5 to indicate signal quality, with
5 being the best. Press SET/ENTER to update
instantaneously
Send test tx
Press SET/ENTER to send a test transmission
Check message now
Press SET/ENTER to check for incoming messages now
GPRS COMx: Test
The GPRS diagnostic menu follows:
Modem status Disabled-Off
Next task Nothing
Next task time None
SelfTimed status ►
Alarm status ►
Power status ►
GPRS status ►
SMS status ►
Signal Display Bars
Signal Strength N/A
Send test tx SET to send
Send SMS message SET to send
Last SMS message rx ►
Send SSP mail SET to send
Last SSP mail rx ►
Turn power on Standby-Off
End Menu
See the following table for descriptions of each function:
Modem Status
The current operation being performed by the modem. For
example, “Starting”, “Standby-Off”, “Standby-On”, “Self
Timed Tx”, “Alarm Tx”, etc.
Next task
The next task to be performed. For example, “Nothing”
(nothing scheduled), “SelfTimed”, “PwrOn”, “PwrOff”, etc.
Next task time
Time of the next scheduled task to perform
SelfTimed status menu:
Last tx
Time of the last self-timed transmission
#Tx today
Number of self-timed transmissions today
Next tx time
Time of the next self-timed transmission
