Sutron Corporation 8310 & 7310 Users Manual 8800-1125Rev. 2.7 (BETA) 4/16/2014 pg. 142
Next Tx msg
The next self-timed message
Nex Tx size
The number of bytes in the next self-timed transmission
Est #Tx bytes/day
Estimated number of bytes per day that will go to
scheduled transmissions, computed based upon the current
message size and transmission schedule
#Tx bytes today
The total number of bytes transmitted today
Alarm status menu:
Last Tx
Time of the last alarm transmission
#Tx today
The total number of alarm transmissions today
#Tx bytes today
The total number of alarm bytes transmitted today
Power status menu:
Status
The current status of the modem (On, Off…)
Last pwr-on
Time of the last power on
Next pwr-on
Time of the next power on
Last pwr-off
Time of the last power off
Next pwr-off
Time of the next power off
GPRS status menu:
#Tx bytes today
Total number of bytes transmitted today
#Rx bytes today
Total number of bytes received today
#Tx/Rx errors
Total number of errors that have occurred while
transmitting or receiving. These are the kinds of errors that
would occur due to having poor view of the sky for the
antenna
Total connect time
The total number of days, hours, minutes, and seconds
connected
SMS status menu:
Last Rx
Time of the last message recieved
#Rx today
Number of message received today
#Tx bytes today
Total number of bytes transmitted today over SMS
#Rx bytes today
Total number of bytes received today over SMS
#Tx/Rx errors
Total number of transmit and receive errors
Signal display
The units to display for signal strength: “Bars” or “dBm”
Signal Strength
Either number of Bars or dBm signal strength
Send test tx
Press SET/ENTER to send a test transmission. The message
will be sent in the background, allowing you to navigate to
other menus. Return to this menu when you wish to check
for the result.
