connection you want to use. With the type and connection defined, the software will display
some details of the connections in /diagnostics/inputs.
AIOx:y
x is the analog module number (1 if
there are no external modules
attached) and y is the input channel.
DIOx:y
x is the digital module number (1 if
there are no external modules
attached) and y is the input
channel.
SDI xy
x is the SDI address and y is the
command
Note that some inputs such as a differential analog signal or quadrature, require connection to
two adjacent channels.
Grounds
The 8310 has three different grounds on the protection/termination board: analog, digital and
chassis.
The analog grounds are labeled with AGND (B1, B5, B9, B12, B15). The analog grounds are tied
together on the protection/termination board and then the signal takes a separate path to the
A/D converter where it is tied to digital ground.
The digital grounds are labeled GND and are wired internally all together from the A, C and D
terminal strips.
The Chassis Ground is a lug or wire that comes off the protection/termination board. All the
surge protection devices connect to the Chassis Ground. The internal metal plates are also
connected to the Chassis Ground. There is a maximum of 100 ohms between the Chassis Ground
and digital ground.
Sensor Setup Examples
The following examples show the details of the 8310 setup for some common sensors.
Shaft Encoder (Quadrature)
Wiring
Quadrature sensors generally require 4 wires, with connections as follows:
Sensor
Wires
Function
Connection
