Red
Power
Prot +12V
(C10)
Black
Ground
Prot Gnd
(C9)
Blue
Signal 1
Digital
Input IN1
or IN3*
Green
Signal 2
Digital
Input IN2
or IN4
*Use either pair of digital inputs: 1&2 or 3&4.
Measurement Setup
The following setup is for the Sutron model 5600-0530 Shaft Encoder.
Field
Value
InputType
QuadSE
Module
1
Channel
Digital Input port number
where Signal 1 is wired
Circumference
Foot
Counts per turn
100
ClockwiseRotation
Yes
QuadSE Units
Feet
SwitchedPwr
None
Processing
Slope-Offset
Slope*
1
Offset
0
Cal Slope
1
Cal Offset
0
*Output value is already converted into either feet or meters (chosen in the QuadSE Units field),
so Slope is typically 1.
Wind Sensor (with amplifier Circuit)
Wiring
The following setup is for the Sutron model 5600-201 Wind Sensor. Note that the sensor must
have the amplifier circuit – the model 5600-0200 without the amplifier cannot be used with the
8310.
Sensor
Wires
Function
Connection
Red
Power
Prot +12V
(C10)
