Sutron Corporation 8310 & 7310 Users Manual 8800-1125Rev. 2.7 (BETA) 4/16/2014 pg. 165
Air Temperature/Relative Humidity
Wiring
The following setup is for the Sutron model 5600-0315 Air Temperature and Relative Himidity
Sensor.
Sensor
Wires
Function
Connection
Green
Power
Prot +5V or
Prot +12V
Grey
Ground
Prot Gnd
White
RH
Analog
Voltage
Analog
Input (any)
Brown
Temp
Analog
Voltage
Analog
Input (any)
Measurement Setup
The 5600-0315 AT/RH sensor outputs two analog voltage signals between 0 and 1 volts. With a
range of -40 to 60 C, it follows that the temperature measurement has slope of 100 and an
offset of -40. The relative humidity measurement, having a range of 0 to 100%, has a slope of
100 and offset of 0. As these are two separate measurements, they each need their own
measurement set up. Alternatively, you could use the DewPoint measurement type and
incorporate them into a single measurement, as seen in the DewPoint section.
Temperature Setup
Relative Humidity Setup
Field
Value
Field
Value
InputType
Voltage
InputType
Voltage
Module
1
Module
1
Channel
Analog Input port number
where Temp signal is wired
Channel
Analog Input port number
where RH signal is wired
Differential
No
Differential
No
FullScale
0-5V/+-2.5V
FullScale
0-5V/+-2.5V
SettlingTime
100
SettlingTime
100
FilterNotch
60
FilterNotch
60
SwitchedPwr
None
SwitchedPwr
None
Processing
Slope-Offset
Processing
Slope-Offset
Slope
100
Slope
100
Offset
-40
Offset
0
Cal Slope
1
Cal Slope
1
Cal Offset
0
Cal Offset
0
DewPoint
Wiring
Use the same sensor and wiring as in the previous AT/RH example.
