Sutron Corporation 8310 & 7310 Users Manual 8800-1125Rev. 2.7 (BETA) 4/16/2014 pg. 166
Measurement Setup
This is much the same as the AT/RH example, but by choosing the measurement type as
DewPoint, you can have outputs of AT, RH and dew point, all incorporated into one single
measurement.
Field
Value
MeasType
DewPoint
TempUnits
Choose Celsius or Fahrenheit.
Applies to both input AT and
output dew point temp.
AT InputType
Voltage
Module
1
Channel
Analog Input port number
where Temp signal is wired
Differential
No
FullScale
0-5V/+-2.5V
SettlingTime
100
FilterNotch
60
SwitchedPwr
None
Processing
Slope-Offset
Slope
100
Offset
-40
Cal Slope
1
Cal Offset
0
RH Input Type
Voltage
Module
1
Channel
Analof Input port where RH
signal is wired
Differential
No
FullScale
0-5V/+-2.5V
SettlingTime
100
FilterNotch
60
SwitchedPwr
None
Processing
Slope-Offset
Slope
100
Offset
0
Cal Slope
1
Cal Offset
0
Thermistor
Wiring
Measuring resistance with the 8310 requires an additional reference resistor. The wiring of a
thermistor setup is shown above, with the reference resistor between VREF and the Analog
