Sutron 8310 - Jumper Configuration

Sutron Corporation 8310 & 7310 Users Manual 8800-1125Rev. 2.7 (BETA) 4/16/2014 pg. 204
Disassembly/Reassembly 8310-O
The following steps can be followed to disassemble an 8310-O.
1. Remove all cabling and grounding from the 8310-O.
2. Use Philips head screwdriver to remove the four screws at the corners of the end panel and
remove end panel.
3. If more than just end panel access is needed, repeat the above step to remove the other end
panel and then remove the six screws for the bottom plate.
CAUTION: Use ESD precautions when the unit is opened up.
Standard port assignments
When configuring the 8310 for communications follow these guidelines:
Use COM2 Satlink
Use COM3 Voice
Jumpers and Connectors 8310
CPU Module Jumpers
Note: 7310 does not support power on COM1 pin9, and does not have COM2 or COM3.
Jumper
Position
Description
J6
See figure below
Com1 pin 9 configuration – Default is RI
J14
See figure below
Com2 pin 9 configuration – Default is RI
J23
See figure below
Com3 pin 9 configuration – Default is RI
Default Jumper position
