More on Measurements
Station Setup/Measurements lists all the measurements defined in the system with their names
and status. Items are also provided for adding and deleting measurements. Each measurement
in the 8310 has a number associated with it to help identify the measurement uniquely, e.g.
“M2”. The “*” after the measurement number indicates that the system is currently making a
measurement. The data on the right gives details about when the next measurement will
happen or its progress in making the measurement.
Measurements (9)
M1*: TEMP > Sample 5 of 6
M2: VBAT > Next: 13:57:00
M3: VBAT_HR > Next: 14:00:00
M4*: AirTemp > Sample 4 of 6
M5: RelHumid > Next: 13:57:00
M6: Stage > Next: 13:57:00
M7*: DewPoint > Executing
M8: testdata > Next: 13:57:00
M9: Stage > Next: 14:00:00
Add Measurement
Delete Measurement
Copy Measurement
Move Measurement
End Measurements
If you want further information about a measurement, use the arrows to display (or highlight) a
particular measurement and press the RIGHT arrow. A display similar to the one below is
displayed. The menu displays all the information needed to make a measurement. The
“Enable” is a master on/off switch that allows you to have measurement setup but not active in
the system. Depending on Meastype selected, you will have additional menu items to specify
the times, intervals and sensor(s) you want to measure.
M1*: TEMP
MeasName TEMP
Enable Yes
MeasType Average
Interval 00:01:00
Time 00:00:10
SampleInterval 00:00:10
SampleDuration 00:01:00
M1.I1: InputType InternalTemp
TempUnits Celsius
Processing Slope-Offset
Slope 1
Offset 0
Cal Slope 1
Cal Offset 0
M1.I1: Cur Val 23.9938 Celsius G
M1.O1*: TEMP 23.981 C G
M1.O2*: TEMPMin > 23.98 G
